Short Description:

G2DA42-12Dual Socket 2U AMD EPYC 9004/9005 Series General Purpose Server

• Application: Big Data Analytics Simulation Computing Financial Quantitative Computing Database Storage Compilation and Decoding
• Processor: Supports 2 AMD EPYC Genoa/Bergamo/Turin Series Processors
• CS (chipset): System on Chip (SoC)
• Memory: Supports up to 24 x DDR5 memory slots and supports RDIMM or LRDIMM modules. Up to 6400 MHz, maximum capacity of up to 6 TB.
• Storage: Supports up to 12 × 3.5"/2.5" SAS/SATA drives for local storage. By default 12 x NVMe drives (SAS/SATA drives require a RAID controller or HBA pass-through card) Local storage supports up to 12 × 3.5"/2.5" SAS/SATA drives. Default configuration 12 x NVMe drives (SAS/SATA drives require a RAID controller or HBA pass-through card)
• Networking: Integrated AST2600 BMC management controller supporting IPMI 2.0, SOL, KVM and virtual media. 1 × dedicated 1 Gbps RJ45 management port (No onboard NIC by default, with optional PCIe standard NICs supporting 1/10/25/50/100/200/400 GE)
• Expansion Slots: Supports 6 standard PCIe slots. By default 2 × PCIe 5.0 x16 GPU slots + 4 × PCIe 5.0 x8 slots + 1 × OCP 3.0 x16 slot and 1 × OCP 3.0 x8 slot.
• Power Supply: Optional 2 x 1300W / 1600W / 2000W CRPS power supply modules with hot-swap support and 1+1 redundancy.
